Win-win, Innovate, Honest, Team, Greatful, Fighting, Pragomatic, Growing
3 Years
| Ask Lasest Price | |
| Brand Name : | Jinze |
| Model Number : | RJ24A-PBA10-TRA |
| Certification : | ISO9001/ROHS/CE/FCC |
| Price : | Negotiation |
| Payment Terms : | T/T |
| Supply Ability : | 80000pcs/ Day |
| Delivery Time : | 15-25 Days |
Speciafications
| RJ45 Housing: | High Temperature Thermo Plastics, PBT, BK, UL94V-0 |
| USB Housing: | High Temperature Thermo Plastics, PBT, BK, UL94V-0 |
| Insert Base: | High Temperature Thermo Plastics, PBT, BK, UL94V-0 |
| Contact: | Copper Alloy |
| Shell: | Steel |
| Contact: | Tin Plating 100u" on Solder tail area |
| USB Contact: | Gold Plating Flash on Contact area, 30u" min Ni underplating over all |
| Voltage Current Rating: | 1.5 AMP. 30V AC |
| Insulation Resistance: | 1000MΩ Min. |
| Contact Resistance: | 40MΩ Max. |
| Dielectric Withstanding Voltage: | 500 V AC |
| Dimension: | 19.05mm*27.50mm*31mm |
| Operating Temperature: | -40°c to +85°c |
Drawings
2D Drawings:
RJ24A-PBA10-TRA.pdf, if you need the Drawing, pls download it
Our advantage
1. Professional connector manufacturer, a variety of styles to
choose from, providing the best EXW price! 100% QC shipping
inspection, quality assurance!
2. We can provide free samples for you to test!
3. We support OEM/ODM. If the product is not what you want, please contact us directly, we will make the best solution for you for free!
4. Large-scale production workshop, fast delivery, immediate delivery, guaranteed delivery.
5. One-to-one after-sales service, please feel free to contact us if you have any questions.
|
|
