| Ask Lasest Price | |
| Brand Name : | Jinze |
| Model Number : | UB09G-0BA4F-RHA |
| Certification : | SGS/ROHS |
| Price : | Negotiation |
| Payment Terms : | T/T |
| Supply Ability : | 80000pcs/ Day |
| Delivery Time : | 15-25 Days |
15u" PA10T USB3.1 Micro USB Pcb Socket Pin Out Female H14.5mm
Specifications:
| Housing | PA10T UL94V-0 Black |
| Contact | C2680, T=0.20mm |
| Shell | SUS201, T=0.3mm |
| Contact Plating | Contact Area: Au 1u" |
| 50u" Min. Matte Tin on Soldertails | |
| 30u" Min. Nickel underplating Over All | |
| Shell Plating | Ni 30u" Min Plated |
| Contact Current Rating | 1.8A for Vbus Pin and Tis Corresponding GND Pin |
| 0.25A for All the other contacts | |
| Contact Resistance | 30mΩ Max for VBUS and GND |
| 50mΩ Max for All other contacts | |
| Insulation Resistance | 100mΩ Min. |
| Dielectric Withstanding Voltage | 100VAC R.M.S |
| Mating Force | 35N(3.57Kgf) Max. |
| Unmating Force | Initial 10N(1.02Kgf) Min. |
| After Test 8N(0.816Kg) Min. | |
| Operating Temperature | -40ºC~+85ºC |
| Salt Spray | 48H Pass |
Images:
UB09G-0BA4F-RHA.pdf, if you need the Drawing, pls download it
A USB connector is the socket, port, or jack into which the plug end of a USB cable or USB-powered device is inserted. USB connectors are typically female, while the USB plug on the cable is male.
Rectangular, slot-shaped USB type-A connectors are most common and can be found on computers, personal electronics, and peripherals. This includes keyboards and mice, mobile phones and chargers, memory sticks (flash drives), and other USB accessories.
|
|
